Description
TIME DELAY RELAY
The TDU Series are encapsulated solid-state, delay-on-make
timers that combine digital timing circuitry with universal voltage
operation. The TDU offers DIP switch adjustment allowing
accurate selection of the time delay over the full time delay
range. This series is an excellent choice for process control
systems and OEM equipment.
Operation (Delay-on-Make)
Upon application of input voltage, the time delay begins. The
output is de-energized before and during the time delay. At
the end of the time delay, the output energizes and remains
energized until input voltage is removed.
Reset: Removing input voltage resets the time delay and output.
