Description
75A 5.5KV MED-VOLT
A550C75-15, Mersen, Amp-Trap Series, Capacitor Protection fuse, medium voltage fuse, A550C-rated, UL listed, current-limiting, high interrupting, non-disconnecting, indicating, 5.5kV max Type 15 external female to bolt, 18A, 65kA@5500V, 1 barrel, 2″ diameter, suitable for capacitor protection.
Mersen capacitor fuses are designed to ANSI C37-41. They are currentlimiting operating without noise or discharge and are designed to be used indoors in a general purpose enclosure or outdoors in a weatherproof enclosure. These are non-disconnecting fuses requiring the use of a disconnect switch. These capacitor fuses provide both short circuit and overload protection and are intended to protect against capacitor case rupture or dielectric failure within the capacitor.
The various mounting configurations offer manufacturers a wide range of cost/space saving solutions and a large choice of equivalent products.
- High interrupting capacity
- Current limitation
- Blown-fuse indication
- Direct mount
- Clip style mount
- Bus mount
- Non-venting for silent operation
Applications
- Capacitor Protection
- Power Factor Correction Equipment
- Harmonic Filtering Equipment
- Induction Heating System
- High Power Drive
- Welders
