$65.48 per piece

A1062715

Brand / Manufacturer: MERSEN (FERRAZ SHAWMUT)

Amperage Rating: 32

Voltage: 690

UPC: 3605340602753

Department: 16

Series: CUS10

Catalog Number: A1062715

Catalog / Class: Fuse Holder

SKU: A1062715

Categories: , , ,

*Prices Subject to Change

Description

MODULOSTAR CUS10 3 POLE

32A 690V 10X38mm Fuse

Mersen’s innovative Modulostar CUS10 fuse holders are finger-safe under IEC standards to an IP20 grade of protection, including fuse changing (with the flick of a finger).
Modulostar CUS10 fuse holders are available in 1, 2, 3 or 4 poles, with or without visual blown fuse indicator, in UL + IEC version.
Multi-pole units can also be field assembled by ordering pin-ties assembly kit. Made of tough and durable thermoplastic or thermoset material.
For use with Mersen midget fuses.

  • Modular design
  • Compact design for space saving
  • DIN rail mounting
  • Degree of protection: IP20
  • Finger safe
  • Easy access to the fuse
  • Lockable without accessory
  • Sealable in closed & open position
  • Optional visual blown fuse indicator
  • Multi-pole assembly kit available
  • Plastic material UL94V2 mini
  • Plastic material R22HL2 for railway application
  • Flame retardant materials with glow wire flammability index to 960°C
  • Schock and vibration tested for marine and railway applications.

Applications

  • All circuits up to 690V for protection of motors, transformers, low voltage distribution, control circuits, drive protection
  • Non-load operation
