Description
30A 750V SC BLOCK
14X51mm SEMICONDUCTOR 3-POLE PRESSURE PLATE FUSE BLOCK
Mersen semiconductor fuse holders feature open face styles. Each
version is rated 750 volts and accommodates 14 x 51 mm or 22 x 58
mm fuses. 703, U705 and U710 holders feature Mersen’s unique adder-
block design which can be snapped onto 1-, 2-, or 3-pole blocks to form
multi-pole segmented blocks of as many poles as desired. A choice of
box, screw or pressure plate connectors is offered to fit a wide range
of standard or solid copper wire. All versions have verified dielectric
strengths in excess of 2500V. A patented built-in DIN-rail adapter on the
U710 blocks adds further design versatility. All fuse clips are made of
high conductivity tin-plated copper with spring reinforced clips.
